Research Article | DOI: https://doi.org/10.31579/IJBR-2021/028

Calculation Deformation of an Engine for Nano Biomedical Research

  • Afonin SM 1*
  • 1* Sergey Mikhailovich, National Research University of Electronic Technology, MIET, 124498, Moscow, Russia

*Corresponding Author: Afonin SM, National Research University of Electronic Technology, MIET, Moscow, Russia

Citation: Afonin SM. (2021). Calculation Deformation of an Engine for Nano Biomedical Research, International J. of Biomed Research 1(5); DOI: 10.31579/IJBR-2021/028

Copyright: © 2021 Afonin SM, This is an open access article distributed under the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.

Received: 01 July 2021 | Accepted: 08 August 2021 | Published: 14 August 2021

Keywords: electromagnetoelastic engine; piezo engine; nano biomedical research; deformation; structural schema; matrix equation; matrix transfer function

Abstract

In the article the calculation of the deformation of an electromagnetoelastic engine for nano biomedical research is obtained. The structural schema of an electromagnetoelastic engine is found. In the visibility of energy conversion the structural schema of an electromagnetoelastic engine has a difference from Cady and Mason electrical equivalent circuits of a piezo vibrator. The matrix equation and the matrix transfer function of an electromagnetoelastic engine are received.

Introduction

In nano biomedical research an electromagnetoelastic engine in the form of piezo engine or magnetostriction actuator is used for laser system, nanopump, nanopositioner, nanomanipulator, scanning microscopy [1-6]. The piezo engine is applied for optical-mechanical device, adaptive optics system, fiber-optic system, microsurgery [5-14].

For an electromagneto elastic engine the electromagnetoelasticity equation and the ordinary differential equation of the second order are solved to obtain the structural schema of an engine. In the visibility of energy conversion the structural schema of an electromagnetoelastic engine has a difference from Cady and Mason electrical equivalent circuits of a piezo vibrator. By applying the methods of electromagnetoelasticity the structural schema of an electro magneto elastic engine for nano biomedical research is obtained [4-12].

Deformation of an engine

The equation electromagnetoelasticity of an electromagnetoelastic engine for nano biomedical research [1-30] has the form

Equation

Where,

Terms

are the relative deformation, the module, the control parameter or the intensity of field, the elastic compliance, and the mechanical intensity.

In static the mechanical characteristic [4-42] of an electromagnetoelastic engine has the form

Mechanical characteristic  of an electromagnet elastic engine

the regulation characteristic an engine has the form

Regulation characteristic an engine

The mechanical characteristic of an electromagnet elastic engine has the form

Characteristic of an electromagneto elastic engine

For the the transverse piezo engine after transforms the maximum values of deformation and force have the form

Maximum values

 the maximum values of deformation and force for the transverse piezo engine are found

Maximum Values

The regulation characteristic at elastic load of an electromagnetoelastic engine for nano biomedical research is obtained in the form

Nano biomedical research

The equation of the deformation at elastic load of an electromagnetoelastic engine for nano biomedical research has the form

Elastic load

After transforms the equation of the deformation at elastic load for the transverse piezo engine for nano biomedical research has the form

Equations
Equations
Figure 1: Structural schema of an electromagnetoelastic engine for nano biomedical research.


For nano biomedical science the structural research of an electromagnetoelastic engine replaces Cady and Mason electrical equivalent circuits [5-10].

The matrix equation of an electro magneto elastic actuator for nano biomedical research with matrix transfer function has the form

Equations



Conclusions

In the article the calculation of the deformation of an electromagnetoelastic engine for nano biomedical research is obtained. The structural schema of an electromagnetoelastic engine for nano biomedical research is shown. In the visibility of energy conversion the structural schema of an electromagnetoelastic engine has a difference from Cady and Mason electrical equivalent circuits of a piezo vibrator.

From the equation electromagnetoelasticity and the ordinary differential equation of the second order of an electro magneto elastic engine the structural schema of an engine is received. The matrix equation and the matrix transfer function of an electromagnetoelastic engine for nano biomedical research are found.
